WUXI YuanYang MACHINERY CO.,LTD

★ Cutting accuracy and precision thanks to the machine solidity

★ High quality on flatness

★ High precise cut to length control

★ High quality on cutting

★ High efficiency for production

★ Delightful man-machine interface

Model	JPY1.0-6.0×1600	JPY2.0-1.0×2000	JPY3.0-12.0×2000	JPY4.0-16.0×2000	JPY8.0-25.0×2500
Coil Material	δs≤230N/mm2,Hot-rolled Coil,Stainless Steel Coil
Coil Thickness	1.0～6.0mm	2.0～10.0mm	3.0～12.0mm	4.0～16.0mm	8.0～25.0mm
Coil Width	800～1600mm	800～2000mm	800～2000mm	1000～2100mm	1000～2500mm
Coil Weight	≤25T	≤25T	≤30T	≤30T	≤40T
Coil I.D	ф508mm, ф610mm, ф760mm	ф610mm～ф820mm	ф610mm～ф820mm	ф610mm～ф820mm	ф610mm～ф820mm
Coil O.D	≤ф2000mm	≤ф2000mm	≤ф2000mm	≤ф2000mm	≤ф2200mm
Cutting Range	500～6000mm	500～12000mm	500～12000mm	500～12000mm	500～12000mm
Cutting Accuracy	±1.0mm	±1.5mm	±1.5mm	±1.5mm	±2.0mm
Line Speed	0～35m/min	0～25m/min	0～25m/min	0～25m/min	0～20m/min
Electrical Control System	PLC Automatic control
